1.Wire for Packing
| Diameter (mm) |
Tolerance (mm) |
| ≦3.00 | ± 0.05 |
| ≧3.01 | ± 0.06 |
2.Wire for Suspension of Electrical Cable Wire
Diameter |
Tolerance |
Breaking Load |
Tensile Strength |
Torsion |
Zinc Value |
Wrapping |
Uniformity |
|
times/60s |
times/30s |
|||||||
2.15 |
± 0.04 |
544 |
150 |
16 |
200 |
6 |
2 |
--- |
2.48 |
± 0.04 |
724 |
150 |
16 |
250 |
6 |
2 |
1 |
2.70 |
± 0.04 |
858 |
150 |
16 |
250 |
6 |
2 |
1 |
2.80 |
± 0.04 |
923 |
150 |
16 |
250 |
6 |
3 |
--- |
3.Wire for Patenting
Spec. |
82B |
72B |
62B |
62A |
57A |
52A |
42A |
Diameter Tolerance (mm) |
± 0.06 |
± 0.06 |
± 0.06 |
± 0.06 |
± 0.06 |
± 0.06 |
± 0.06 |
Tensile Strength (kg/mm2) |
105~135 |
95~125 |
85~115 |
80~110 |
75~110 |
70~105 |
68~98 |
Elongation(%) |
6.0 |
||||||
Torsion (times) |
15 |
||||||
Zinc Coating(g/m2) |
150 |
||||||
4.A.C.S.R.
Composition |
Ｃ |
Ｍｎ |
Ｐ |
Ｓ |
Ｓｉ |
Contents % |
0.53~0.86 |
0.3~0.9 |
＜0.035 |
＜0.035 |
0.15~0.35 |
Diameter |
Tolerance |
Tensile Strength Class A (kg/mm2) |
Elongation Class |
Zinc Value Class |
Primary Loading |
Elongation Setting |
|
(kg/mm2) |
1% of Elongation |
||||||
1.270~1.521 |
+ 0.038 |
148 |
137 |
3.0 |
183 |
10.2 |
0.05 |
1.524~1.902 |
198 |
||||||
1.905~2.283 |
+ 0.051 |
214 |
|||||
2.286~2.639 |
144 |
131 |
3.5 |
229 |
19.4 |
0.10 |
|
2.642~3.045 |
244 |
||||||
3.048~3.553 |
+ 0.076 |
144 |
127 |
4.0 |
259 |
29.6 |
0.15 |
3.556~4.569 |
+ 0.102 |
141 |
120 |
4.0 |
274 |
||
4.572~4.822 |
305 |
||||||
